Salient Features
- GMP model, Easy Cleaning & Low Maintenance
- Specially designed to suit in line De-Dusting needs
- Multi Layer De-dusting with long route, automatic turning of tablets, High Efficiency to wipe out burrs and dust from the tablets
- Compatible with any Tablet Press Machine and Metal Detector
- De-dusting through Vibration, Compressed Air and Dust Extractor
- De-dusting of tablets, cleaning of tablets through compressed air and movement of tablets to upward direction at the same time
- Elevating type, Easy Operation and High Efficiency
- Stainless Steel cylinder with acrylic glass window
- Product conveying through continuously adjustable vibration
- Adjustable speed through control system
- All contact parts with stainless steel 316, which can be easily washed
| TECHNICAL SPECIFICATION | |
| Model | VM-DDEL-230 |
| Output(for 8mm tablet ) * | 5,000 to 2,50,000 Tablets / Hr. |
| Max. De-dusting Route (m) | 6 |
| Max. Upward Conveying (mm) | Approx. 460 |
| Max. Tablet Diameter | 16 mm |
| Min. Tablet Diameter | 5 mm |
| Power Supply | 220/230 V, 50 Hz / 1 Ph./ AC |
| Cleaning Air Source | 0.1m3/min 0.15~ 0.2 MPa |
| Overall Dimension (mm) | 530 (L) X 400 (W) X 1400 (H) |
| Net Weight | 70 Kgs |
| Depending upon tablet shape & size | |
