Features:
- Robust with high quality Engineering
- Medium batch production
- Safe/ simple to operate and easy to maintain
- Designed as per GMP standards
Technical Specification
| TECHNICAL SPECIFICATIONS | |||
| Model | VM-D-27 | VM-B-35 | VM-BB-45 |
| Type of Tooling | D | B | BB |
| No. of Stations | 27 | 35 | 45 |
| Output Tablets/Hr.* | 50000 to 129000 | 70000 to 168000 | 90000 to 216000 |
| Max. Operating Pressure | 10 Tons | 6.5 Tons | 6.5 Tons |
| Max. Tablet Diameter | 23 mm | 16 mm | 11.11 mm |
| Max. Depth of Fill | 20 mm | 17.5 mm | 17.5 mm |
| Upper Punch Penetration | 1.5 to 8 mm | 1.5 to 8 mm | 1.5 to 8 mm |
| Main Electric Motor | 3.70 kW / 5Hp / 1440 RPM / 415 V / 50 Hz / 3 Ph | ||
| * Depending upon the characteristics of material, shape & size of tablets NOTE: DUE TO CONTINIOUS IMPROVEMENTS IN THE MACHINERIES, SPECIFICATION OF THE MACHINERIES IS SUBJECT TO CHANGE WITHOUT ANY PRIOR NOTICE. |
|||
